Laserworld FX-700 Hydro

Laserworld FX-700 Hydro main image
The Laserworld FX-700 Hydro is an RGB whitelight effects laser that is built IP65 waterproof, which makes it perfectly suitable for outdoor use. It projects a multitude of laser dots, different colors including white can be applied, as well as various fade and strobe effects.
Class 3R laser system!
  • RGB color mixture, including white
  • Analog color modulation
  • Stand-alone operation
  • DMX control
  • Strobe effects
  • Fade effects
  • Class 3R
    Laserworld_FX-700_Hydro-0002_beam.jpg laser image 0
    Laserworld_FX-700_Hydro-0004_beam.jpg laser image 1
    Laserworld_FX-700_Hydro-0010_beam.jpg laser image 2
    Laserworld_FX-700_Hydro-0012_beam.jpg laser image 3
    Laserworld_FX-700_Hydro-0005_beam.jpg laser image 4
    Laserworld_FX-700_Hydro-0008_beam.jpg laser image 5
    Laserworld_FX-700_Hydro-0001_beam.jpg laser image 6
    Laserworld_FX-700_Hydro-0013_beam.jpg laser image 7
    Laserworld_FX-700_Hydro-0003_beam.jpg laser image 8
    Laserworld_FX-700_Hydro-0009_beam.jpg laser image 9
    Laserworld_FX-700_Hydro-0014_beam.jpg laser image 10
    Laserworld_FX-700_Hydro-0006_beam.jpg laser image 11
    Laserworld_FX-700_Hydro-0011_beam.jpg laser image 12
    Laserworld_FX-700_Hydro-0007_beam.jpg laser image 13
    Stand-Alone modeSTAND-ALONE MODE:
    The laser operates stand-alone and does not need and control. It plays back the content stored on the laser's mainboard.
    DMX modeDMX MODE:
    The laser can be controlled with a standard DMX controller or DMX software.
    Master-Slave modeMASTER-SLAVE MODE:
    One laser sends control commands, the other laser follows these. Works with Stand-Alone modes and Sound-to-Light modes.
Laserworld FX-700 Hydro additional image 1
Laserworld FX-700 Hydro additional image 2
Laserworld FX-700 Hydro additional image 3
Laserworld FX-700 Hydro additional image 4
Laserworld FX-700 Hydro additional image 5
The Laserworld FX-700 Hydro is a waterproof effects laser that was specifically designed for outdoor use. The strong power of makes the laser dots very well visible, even though the whole unit is rated as class 3R laser system - thanks to the distribution of the overall power to the multiple dots.
It is equipped with analog modulated RGB laser sources that can also create white.

Due to the deflection of the effect the Laserworld FX-700 Hydro can cover a large area. The deflection angle is approximately 60°.

The multi-mirror deflection unit can rotate in both directions and at different speeds, which can either be controlled via the back panel menu or DMX.

The operation mode settings can be adjusted with the control knobs at the back side of the unit, which are also built waterproof.

The whole system is rated waterproof according to the specifications of IP65. The housing of the laser is made of very robust metal. The whole unit is passively cooled, so no fans are required.

The Laserworld FX-700 Hydro has 5m long cables for connecting power and DMX in as well as DMX through. This helps for outdoor installations, as not only the unit itself is waterproof, but can also be mounted in a way that the connections are not exposed to environmental influences.

Perfect for unattended installations, no requirements for e-stop or key switch due to it being class 3R.



> More details

Laserworld FX-700 Hydro laser beam and explanatory image 6
Laserworld FX-700 Hydro laser beam and explanatory image 7
Laserworld FX-700 Hydro laser beam and explanatory image 8
Laserworld FX-700 Hydro laser beam and explanatory image 9
Laserworld FX-700 Hydro laser beam and explanatory image 10
Laserworld FX-700 Hydro laser beam and explanatory image 11
Laserworld FX-700 Hydro laser beam and explanatory image 12
Laserworld FX-700 Hydro laser beam and explanatory image 13
Laserworld FX-700 Hydro laser beam and explanatory image 14
Laserworld FX-700 Hydro laser beam and explanatory image 15
Laserworld FX-700 Hydro laser beam and explanatory image 16
Laserworld FX-700 Hydro laser beam and explanatory image 17
Laserworld FX-700 Hydro laser beam and explanatory image 18
Laserworld FX-700 Hydro laser beam and explanatory image 19



> More details

Total Power
700 mW
Power Red
200 mW / 638 nm
Power Green
220 mW / 520 nm
Power Blue
300 mW / 450 nm
Scanner
Multi-mirror-reflection
Laser Source
Diode
Laser Class
3R
Operation Modes
Stand-alone mode, DMX control, master-slave
Accessories
Manual, DMX Adapters, Mounting-bracket
IP rating
IP65
Power Supply
85-250 V AC 50/60 Hz
Power Consumption
15 W
Dimensions
240 x 125 x 95 mm
Weight
2.4 kg
EAN / MPN
7640144997373
*Due to Advanced Optical Correction technology used in our laser systems the optical power of each colour within installed laser module(s) may slightly differ from the specification of respective laser module(s). Divergence FWHM average depending on model.
