Remaining Stock Item
Laserworld PL-30 FB4 (1 pc)
Remaining Stock Item - only as long as stock lasts!Remaining Stock Item - Only as long as Stock lasts!
Sample, nearly new
The latest generation of Purelight IP65 laser systems features innovative RSL2 technology, which combines an extremely compact and lightweight design with outstanding beam quality. Delivering 30'000 mW of power and featuring an IP65 rating, the Laserworld PL-30 FB4 (1 pc) is a great choice for large-scale club installations, touring and production, and large outdoor shows. Its 40 kpps @ 8° scanning system ensures it is fully capable of handling professional graphics projections.
Each device features an integrated FB4 mainboard and a built-in color display for easy operation mode configuration. This hardware allows the Purelight Series to be controlled directly via various laser software or integrated into lighting setups via DMX and Art-Net.
The latest generation of Purelight IP65 laser systems features innovative RSL2 technology, which combines an extremely compact and lightweight design with outstanding beam quality. Delivering 30'000 mW of power and featuring an IP65 rating, the Laserworld PL-30 FB4 (1 pc) is a great choice for large-scale club installations, touring and production, and large outdoor shows. Its 40 kpps @ 8° scanning system ensures it is fully capable of handling professional graphics projections.
Each device features an integrated FB4 mainboard and a built-in color display for easy operation mode configuration. This hardware allows the Purelight Series to be controlled directly via various laser software or integrated into lighting setups via DMX and Art-Net.
- RSL2 module, optimized optical performance and a more compact housing
- Graphics capable – 40 kpps @ 8°
- Maximum scan angle: 50°
- Full color mixing – analog modulation
- Sharp, intense beams – ca. 6.5 mm
- IP65 waterproof housing
- Save safety settings directly to the laser (applies in all modes)
- Link multiple units with Power, DMX, and ILDA linking
- Multiple control modes: Auto, DMX, Art-Net, and ILDA
- Including waterproof flightcase
- Integrated Pangolin FB4 interface
Special Remaining Stock Price:
5,950.00 €
excl. VAT, excl. shipping
price per unit
price per unit
STAND-ALONE MODE:The laser operates stand-alone and does not need and control. It plays back the content stored on the laser's mainboard.
DMX MODE:The laser can be controlled with a standard DMX controller or DMX software.
ArtNET Control mode
LAN MODE:The laser can be controlled over LAN - this can be either direct software control, or ArtNET or similar (depending on the main board)
ILDA MODE:The laser can be controlled over standard ILDA, the analog control signal for laser control. External Digital-Analog-Converters (DACs) can be used.
FB4 INTEGRATED:The laser can be controlled through the integrated Pangolin FB4 board
The Laserworld PL-30 FB4 (1 pc) laser system is equipped with RSL2 module technology, which was originally developed by LaserAnimation Sollinger. This technology enables an extremely small and lightweight housing while simultaneously improving beam quality. With its 30'000 mW of power, an IP65 rating and 40 kpps @ 8° scanners, the Laserworld PL-30 FB4 (1 pc) is a great choice for large-scale club installations, touring and production, and large outdoor shows as well as complex graphics projections. This RSL2-based full color diode laser system provides analog modulation for linear color fading combined with great visibility.
Laserworld PL-30 FB4 (1 pc) lasers include the FB4 mainboard, allowing for various control options including DMX and Art-Net, as well as direct computer control via network (QuickShow or BEYOND software). Custom effects and animations can be uploaded from the software to be triggered by DMX/Art-Net and adjusted live in color, position, or with additional effects.
The Laserworld PL-30 FB4 (1 pc) has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 30'000 mW, with individual RGB values of 9'500 mW / 638 nm, 11'000 mW / 520 nm, and 14'000 mW / 450 nm. It offers a scan speed of 40 kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is perfectly suited for outdoor use and reduces maintenance requirements to an absolute minimum.
Laserworld PL-30 FB4 (1 pc) lasers include the FB4 mainboard, allowing for various control options including DMX and Art-Net, as well as direct computer control via network (QuickShow or BEYOND software). Custom effects and animations can be uploaded from the software to be triggered by DMX/Art-Net and adjusted live in color, position, or with additional effects.
The Laserworld PL-30 FB4 (1 pc) has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 30'000 mW, with individual RGB values of 9'500 mW / 638 nm, 11'000 mW / 520 nm, and 14'000 mW / 450 nm. It offers a scan speed of 40 kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is perfectly suited for outdoor use and reduces maintenance requirements to an absolute minimum.
> More details
Guaranteed Power at aperture
30'000 mW
Power Red
9'500 mW / 638 nm
Power Green
11'000 mW / 520 nm
Power Blue
14'000 mW / 450 nm
Beam Specifications*
ca. 6.5 mm / 0.9 mrad
Scanner
40 kpps @ 8°
Max. Scan Angle
50°
Laser Source
Diode
Laser Class
4
Operation Modes
FB4, ILDA, DMX
Basic Patterns
Available for download
Accessories
Waterproof plastic case, power cable, manual, interlock, keyhtcase
Power Supply
85 V - 250 V / AC, 50/60 Hz
Power Consumption
450 W
Dimensions
365 x 234 x 232 mm (L x W x H)
Weight
16 kg
EAN / MPN
R908057
Download Technical Datasheet
*Due to Advanced Optical Correction technology used in our laser systems the optical power of each colour within installed laser module(s) may slightly differ from the specification of respective laser module(s). Divergence FWHM average depending on model.
