Laserworld ScanBar 10RGB
- 10039 W guaranteed power
- 5 x RGB Diode Modules
- 5 x X/Y Scanners - 25kpps at 8°
- Full color mixing - analog modulation
- Extremely sharp beams - low divergence
- Professional DMX with four different profiles
- 10039 W guaranteed power
- 5 x RGB Diode Modules
- 5 x X/Y Scanners - 25kpps at 8°
- Full color mixing - analog modulation
Bestens geeignet für
Architektur, Werbung
Kunst und Illumination
Mobile DJs, Hochzeiten
LASERWORLD
Laserworld ScanBar 10RGB
The Laserworld ScanBar 10RGB is a white-light RGB laser with analog modulation and . It's controlled via four DMX profiles, making it easy to integrate into existing lighting setups. Each beam output features its own X/Y scan set with 25kpps at 8°. In addition to single-beam projection, the Laserworld ScanBar 10RGB offers >100 pre-set patterns.
The Laserworld ScanBar 10RGB is equipped with RGB laser diode modules, with each RGB module delivering a power of 5 x 450 mW / 638 nm red, 5 x 600 mW / 525 nm green, and 5 x 950 mW / 450 nm blue. These power values are measured after the apertures.
Controlled via DMX profiles, the Laserworld ScanBar 10RGB is compatible with all current DMX controllers. This Laserworld ScanBar 10RGB can be effortlessly integrated into an existing lighting setup.
It's a great visual effect for large events.
The Laserworld ScanBar 10RGB is equipped with RGB laser diode modules, with each RGB module delivering a power of 5 x 450 mW / 638 nm red, 5 x 600 mW / 525 nm green, and 5 x 950 mW / 450 nm blue. These power values are measured after the apertures.
Controlled via DMX profiles, the Laserworld ScanBar 10RGB is compatible with all current DMX controllers. This Laserworld ScanBar 10RGB can be effortlessly integrated into an existing lighting setup.
It's a great visual effect for large events.
STAND-ALONE MODE:
The laser operates stand-alone and does not need and control. It plays back the content stored on the laser's mainboard.
The laser operates stand-alone and does not need and control. It plays back the content stored on the laser's mainboard.
DMX MODE:
The laser can be controlled with a standard DMX controller or DMX software.
The laser can be controlled with a standard DMX controller or DMX software.
MASTER-SLAVE MODE:
One laser sends control commands, the other laser follows these. Works with Stand-Alone modes and Sound-to-Light modes.
One laser sends control commands, the other laser follows these. Works with Stand-Alone modes and Sound-to-Light modes.
For Dealers and Distribution Partners
See all prices and availability.
Subscribe to newsletter
Stay up to date with the latest news.
Technical Details
| Guaranteed Power at aperture | 10'000 mW |
| Power Red | 5 x 450 mW / 638 nm |
| Power Green | 5 x 600 mW / 525 nm |
| Power Blue | 5 x 950 mW / 450 nm |
| Beam Specifications | 4 mm / 1.1 mrad |
| Scanner | 25kpps at 8° |
| Laser Source | Diode |
| Laser Class | 4 |
| Operation Modes | DMX, stand-alone, Sound-to-Light |
| Basic Patterns | >100 |
| Accessories | power cable, manual, interlock, key |
| Power Supply | 85 V - 250 V AC, 50/60 Hz |
| Power Consumption | 150 W |
| Dimensions | 1000 x 152 x 105 mm (L x W x H) |
| Weight | 12 kg |
| EAN / MPN | 7640144994815 |
| Delivery Scope | power cable, manual, interlock, key |
*Due to Advanced Optical Correction technology used in our laser systems the optical power of each colour within installed laser module(s) may slightly differ from the specification of respective laser module(s). Divergence FWHM average depending on model.
