Laserworld PL-30
The latest generation of Purelight IP65 laser systems features innovative RSL2 technology, which combines an extremely compact and lightweight design with outstanding beam quality. Delivering 30'000 mW of power and featuring an IP65 rating, the Laserworld PL-30 is a great choice for large-scale club installations, touring and production, and larger outdoor shows. Its 45kpps @ 8° scanning system ensures it is fully capable of handling professional graphics projections.
Each device features an integrated ShowNET mainboard and a built-in color display for easy operation mode configuration. This powerful hardware allows the Purelight Series to be controlled directly via LAN connection using various laser software or integrated into professional lighting setups via DMX and ArtNet.
Each device features an integrated ShowNET mainboard and a built-in color display for easy operation mode configuration. This powerful hardware allows the Purelight Series to be controlled directly via LAN connection using various laser software or integrated into professional lighting setups via DMX and ArtNet.
- Innovative RSL2 module technology for optimized optical performance and a compact housing
- Minimum power at aperture: 30'000 mW
- Professional graphics capable – 45kpps @ 8°
- Maximum scan angle: 50°
- Sharp, intense beams – ca. 6.5 mm
- IP65 waterproof housing – ideal for outdoor use
- Save safety settings directly to the ShowNET mainboard
- Link multiple units with Power, DMX, and ILDA linking
- Free computer control software (Showeditor) included – upgradable to Showcontroller
- Multiple control modes: Auto, DMX, ArtNet, and ILDA
- Built-in display for easy selection of operating modes
- Including waterproof flightcase
ShowNET-Mainboard als Standard:
- Vielfältige Steuerungsmöglichkeiten: ILDA, Professionelles DMX (zwei Modi), LAN (Computersteuerung, integrierter DAC)
- Eigene Inhalte erstellen, im Laser speichern und in verschiedenen Modi wiedergeben
- Kostenlose Lasershow-Steuerungssoftware enthalten
DMX MODUS:Der Laser kann mit einem Standard-DMX-Controller oder einer DMX-Software gesteuert werden.
NETZWERK-MODUS:Der Laser kann über LAN gesteuert werden - dies kann entweder eine direkte Softwaresteuerung sein, oder ArtNET oder ähnliches (abhängig vom Mainboard)
ILDA-MODUS:Der Laser kann über Standard-ILDA, das analoge Steuersignal für die Lasersteuerung, gesteuert werden. Es können externe Digital-Analog-Wandler (DACs) verwendet werden.
SHOWNET INSIDE:Der Laser ist mit dem fortschrittlichen ShowNET-Laser-Mainboard ausgestattet, das den Laser um eine Vielzahl von Funktionen erweitert und ihn zu einem intelligenten Lichteffektgerät macht.
SHOWEDITOR INKLUSIVE:Die Vollversion der Lasershow-Steuerungssoftware Showeditor ist im Lieferumfang enthalten.
The Laserworld PL-30 laser system is equipped with RSL2 module technology, which was originally developed by LaserAnimation Sollinger. This technology enables an extremely small and lightweight housing while simultaneously improving beam quality. With its 30'000 mW of power, an IP65 rating and 45kpps @ 8° scanners, the Laserworld PL-30 is a great choice for large-scale club installations, touring and production, and large outdoor shows as well as complex graphics projections. This RSL2-based full color diode laser system provides analog modulation for linear color fading combined with great visibility.
Laserworld PL-30 lasers include the ShowNET intelligent mainboard with an integrated digital-to-analog converter (DAC), allowing for direct control via software such as Showcontroller, Showeditor, TouchDesigner, MadLaser, or ILD-Render. It can also be used with any ILDA laser control software when using an external interface like LaserGraph DSP. Additionally, the unit comes standard with built-in memory containing preset patterns accessible via DMX or ArtNet. It is also possible to create custom ILDA content and upload it to the mainboard using the included Showeditor software license. Besides that, the Laserworld PL-30 can operate in automatic mode, which is ideal for advertising, corporate productions, or automated laser shows.
The Laserworld PL-30 has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 30'000 mW, with individual RGB values of 9'500 mW / 638 nm, 11'000 mW / 520 nm, and 14'000 mW / 450 nm. It offers a scan speed of 45kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is perfectly suited for outdoor use and reduces maintenance requirements to an absolute minimum.
Laserworld PL-30 lasers include the ShowNET intelligent mainboard with an integrated digital-to-analog converter (DAC), allowing for direct control via software such as Showcontroller, Showeditor, TouchDesigner, MadLaser, or ILD-Render. It can also be used with any ILDA laser control software when using an external interface like LaserGraph DSP. Additionally, the unit comes standard with built-in memory containing preset patterns accessible via DMX or ArtNet. It is also possible to create custom ILDA content and upload it to the mainboard using the included Showeditor software license. Besides that, the Laserworld PL-30 can operate in automatic mode, which is ideal for advertising, corporate productions, or automated laser shows.
The Laserworld PL-30 has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 30'000 mW, with individual RGB values of 9'500 mW / 638 nm, 11'000 mW / 520 nm, and 14'000 mW / 450 nm. It offers a scan speed of 45kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is perfectly suited for outdoor use and reduces maintenance requirements to an absolute minimum.
> Mehr Details
ShowNET interne Steuerung:
DMX Control
ArtNet Control
Automatic / Stand Alone
Master-Slave
ILDA Streaming
Externe ILDA Standard Ansteuerung:
Analog ILDA
> Mehr Details
