Laserworld PL-20 FB4
The latest generation of Purelight IP65 laser systems features innovative RSL2 technology, combining an extremely compact, lightweight design with outstanding beam quality. With 20'000 mW of power and an IP65 rating, the Laserworld PL-20 FB4 is a dependable choice for large-scale club installations, touring and production, and larger outdoor shows. Its 45 kpps @ 8° scanning system ensures it is fully capable of handling professional graphics projections.
Each device features an integrated FB4 mainboard and a built-in color display for easy operation mode configuration. This hardware allows the Purelight Series to be controlled directly via various laser software, or integrated into lighting setups via DMX and Art-Net.
Each device features an integrated FB4 mainboard and a built-in color display for easy operation mode configuration. This hardware allows the Purelight Series to be controlled directly via various laser software, or integrated into lighting setups via DMX and Art-Net.
- RSL2 module, optimized optical performance and more compact housings
- Graphics capable - 45 kpps @ 8°
- Max scan angle 50°
- Full colour mixing - analog modulation
- Sharp intense beams – ca. 6.5 mm
- IP65 waterproof housing
- Save safety settings direct to the laser and they apply in all modes
- Link multiple units with linking Power, DMX and ILDA
- Multiple control modes - Auto,DMX, Artnet and ILDA
- including waterproof flightcase
- Pangolin FB4 Interface
DMX MODUS:Der Laser kann mit einem Standard-DMX-Controller oder einer DMX-Software gesteuert werden.
NETZWERK-MODUS:Der Laser kann über LAN gesteuert werden - dies kann entweder eine direkte Softwaresteuerung sein, oder ArtNET oder ähnliches (abhängig vom Mainboard)
ILDA-MODUS:Der Laser kann über Standard-ILDA, das analoge Steuersignal für die Lasersteuerung, gesteuert werden. Es können externe Digital-Analog-Wandler (DACs) verwendet werden.
FB4 INTEGRIERT:Der Laser kann über die integrierte Pangolin FB4-Karte gesteuert werden
The Laserworld PL-20 FB4 laser systems is equipped with the RSL2 module technology, which was initially developed by LaserAnimation Sollinger. This leads to an extremely small and lightweight housing with improved beam quality at the same time. With its 20'000 mW of power, an IP65 rating and 45 kpps @ 8° scanners, the Laserworld PL-20 FB4 is a great choice for large-scale club installations, touring and production, and larger outdoor shows as well as complex graphic projections. These RSL2 based full color diode laser system offers an analog modulated, linear color fading combined with great visibility.
Laserworld PL-20 FB4 lasers include the FB4 mainboard, allowing various control options, including DMX, ArtNet as well as direct computer control via network (QuickShow or BEYOND software). Custom effects and animations can be uploaded from the software and the be triggered by DMX/ArtNet and adjusted live in color, position or with additional effects.
The Laserworld PL-20 FB4 has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 20'000 mW, with individual RGB values of 5'500 mW / 638 nm, 8'000 mW / 520 nm, and 9'000 mW / 450 nm. It offers a scan speed of 45 kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is not only perfectly suited for outdoor use but also reduces maintenance requirements to an absolute minimum.
Laserworld PL-20 FB4 lasers include the FB4 mainboard, allowing various control options, including DMX, ArtNet as well as direct computer control via network (QuickShow or BEYOND software). Custom effects and animations can be uploaded from the software and the be triggered by DMX/ArtNet and adjusted live in color, position or with additional effects.
The Laserworld PL-20 FB4 has a beam diameter and divergence of ca. 6.5 mm / 0.9 mrad. The guaranteed output power is 20'000 mW, with individual RGB values of 5'500 mW / 638 nm, 8'000 mW / 520 nm, and 9'000 mW / 450 nm. It offers a scan speed of 45 kpps @ 8° and a maximum scan angle of 50°. Thanks to its IP65 rating, the laser is not only perfectly suited for outdoor use but also reduces maintenance requirements to an absolute minimum.
